Impact Crusher

Type: Secondary Crushing Input Size: 250-500mm Processed Materials: Stone with compression strength lower than 350Mpa, such as limestone, gypsum, concrete, etc. Application: Ore crushing, railway, highway, energy, cement, chemical industry, construction, etc.

Impact breaker can be used in stone crushing plant to crush materials whose side length is 100~500mm. This machine has many advantages such as big crushing ratio and good particle shape.

Get a Quote Services Online
Detailed Description

Introduction to China Impact Crusher

Impact breaker can be used in stone crushing plant to crush materials whose side length is 100~500mm. This machine has many advantages such as big crushing ratio and good particle shape. The feeding mouth of Hongxing rock impact crusher can reach as big as 1315mm and 1520mm.

Impact crushing machine can be used for crushing stone, coal and cement clinker, so that its application range is very wide. The rough working principle of stone impact crusher goes like this: After materials go into the crushing chamber, they will meet the hammers rotating with high speed and be hit by the hammers. Big materials will immediately be crushed and the crushed materials will fly to the impact plate with high speed and be crushed again, and the bounced materials will hit and crush the materials that continue to fly near, thus reaching the goal of crushing.

Impact Crusher

A impact pulverizer can be divided into common impact pulverizer and coal impact pulverizer, among which, coal impact pulverizer is mainly used for the coal crushing in thermal power plant and coal mining and it usually has only one rotor.

Compared with cone crusher, impact stone crusher has lower investment, better particle shape and lower production cost. Compared with hammer crusher machine, impactor crusher has longer service life of the wearing parts, higher production efficiency and lower follow-up investment.

Technical Parameters
Model Specification
(mm)
Feed
opening
(mm)
The Maximum
Feeding Size
(mm)
Capacity
(t/h)
Power
(kw)
Overall
dimension
(L×W×H)
(mm)
Total
weight
(t)
PF-1007 Φ1000×700 400×730 300 30-70 4P   37-45 2330×1660×2300 12
PF-1010 Φ1000×1050 400×1080 350 50-90 4P   45-55 2370×1700×2390 15
PF-1210 Φ1250×1050 400×1080 350 70-130 6P   110 2680×2160×2800 17.7
PF-1214 Φ1250×1400 400×1430 350 80-180 6P   132 2650×2460×2800 22.4
PF-1315 Φ1320×1500 860×1520 500 100-280 6P   200 3180×2720×2620 27
PF-1320 Φ1300×2000 993×2000 500 140-380 6P   250 3220×3100×2620 34
PF-1520 Φ1500×2000 830×2040 700 200-550 4P   315-400 3959×3564×3330 50.6
PF-1820 Φ1800×2000 1260×2040 800 400-800 4P   630-710 4400×3866×4009 83.21
